Chemical modifications on histones and DNA/RNA constitute a fundamental mechanism for epigenetic regulation. These modifications often function as docking marks to recruit or stabilize cognate “reader” proteins. So far, a platform for quantitative and high-throughput profiling of the epigenetic interactome is urgently needed but still lacking. Here, we report a 3D-carbene chip-based surface plasmon resonance imaging (SPRi) technology for this purpose. The 3D-carbene chip is suitable for immobilizing versatile biomolecules (e.g., peptides, antibody, DNA/RNA) and features low nonspecific binding, random yet function-retaining immobilization, and robustness for reuses. We systematically profiled binding kinetics of 1,000 histone “reader–mark” pairs on a single 3D-carbene chip and validated two recognition events by calorimetric and structural studies. Notably, a discovery on H3K4me3 recognition by the DNA mismatch repair protein MSH6 in Capsella rubella suggests a mechanism of H3K4me3-mediated DNA damage repair in plant.

The application scope of surface plasmon resonance (SPR) and SPR imaging (SPRi) is rapidly growing, and tools such as high-performance and low-cost slides could enable more rapid growth of the field. We describe herein a novel silver slide, addressing the inherent instability of plain silver structure by improving adhesion between the glass substrate and the silver layer with a thin buffer layer of gold. Covered by a self-assembled monolayer (SAM) only, SPR characteristics of the slide remain steady for more than 3 months under regular storage. In a bioassay, the slide substantiates the predicted nearly 100% sensitivity improvement over gold slides and exhibits exceptional performance stability as determined by sensitivity and resolution measurements during the extended 40 000 s multicycle experiment. We demonstrate the suitability of this new slide for large-area SPRi, describing analysis results from a 1 296-ligand protein microarray. We predict this slide structure will provide a stable, high-sensitivity solution for high-throughput SPRi applications and other surface analysis platforms.

The silver surface plasmon resonance (SPR) sensor has long been explored due to its intrinsic sensitivity enhancement over the conventional single-layered gold SPR sensor. However, the silver SPR sensor has not been exploited for practical applications because of pronounced instability problems. We propose a novel gold–silver–gold trilayered SPR sensor chip, in which an extra buffer layer of gold is added between the silver and substrate adhesion layer (i.e., chromium) compared to the previously reported silver–gold bilayered SPR sensors. Subjected to prolonged agitation in phosphate-buffered saline (PBS) solution, the new chip exhibited high integrity according to both optical and atomic force microscopy (AFM) analysis. Having undergone repeated cycles of calibration, binding, and regeneration in various chemical solutions, 25 regions of interest (ROIs) over a 14 mm ×14 mm area were chosen and monitored by large detection area SPR microscopy; the new sensor chip exhibited stability comparable to the single gold layered SPR chip. In terms of sensing performances, over 50% increases in sensitivity and signal-to-noise ratio (S/N) than those of the single gold layered SPR chip were determined by SPR microscopy at 660 nm. Protein arrays of protein A and bovine serum albumin (BSA) on both the new chip and single-layered gold SPR chip were fabricated and underwent biomolecular interactions with human IgG, for the purpose of consistency, comparison on kinetics parameters, values from the microarray trilayered chip showed reasonable consistency with those from the single gold layered SPR chip. This study suggests that the new chip is a viable alternative to the conventional single gold layered SPR chip with improved sensing performances.

•A multi-functional polycarbonate film was prepared by a simple casting process.•The polymer film showed highly hydrophobicity, heat-resistance and transparency.•The high hydrophobicity could be retained up to 390 °C.•The polymer film may have potential applications in aerospace and food industries.A multi-functional polymer film with high hydrophobicity and transparency was formed by simple casting of a polycarbonate solution onto a substrate having micro-scale roughness. The high hydrophobicity was heat-resistant, which can be retained up to 390 °C. The polymer film may have potentially wide-ranging applications in industry and high technology.

Voltage scanning surface plasmon resonance (VSSPR) detection is realized by a metal/electro-optic dielectric/metal (MEM) three-layer sensor chip used in a prism-coupled attenuated total reflection (ATR) setup. Sweeping DC voltage is applied and recorded in real time with a fixed incident angle near the resonant angle. The VSSPR curve is defined by the reflected intensity and the applied voltage. It is observed experimentally that the resonant voltage obtained by the centroid method varied linearly with the concentration of the analytes and can be used as a characteristic and quantitative parameter to describe the SPR effect. This method can be used for refractive index detection, and also have potential applications in surface plasmon resonance imaging systems.

An electro-optically modulated intensity interrogation method based on tunable waveguide coupled surface plasmon resonance sensors has been proposed. It has been theoretically and experimentally demonstrated that the proposed scheme can enable sensitive measurement of measurand variations. By modulating the refractive index in the waveguide layer, this interrogation method yields modulated signal whose amplitude is related to measurand's refractive index. This amplitude modulated signal offers a higher signal to noise ratio and eliminates additive noise in the sensor system. A preliminary investigation using saline buffers with different NaCl concentrations shows a resolution of 2.3 × 10−6 refractive index unit by our approach. Resolution can be controlled by the amplitude of the applied modulation voltage and can be further enhanced by optimizing the device structure or improving the electro-optical (E-O) coefficient of the E-O material. This approach is simple, stable, and promising for low-cost or multi-channel SPR biosensor applications.
